Max. 14A PV input current per string
97.6% max. efficiency
Modular all in one design, quick installation with plug&play
Flexible battery capacity expansion, 5~30kWh
IP65 rating, indoor and outdoor installation
LiFePO4 battery cell, safety and reliable
Real-time monitoring and parameter control through APP
Ideal for residential application with low operating noise
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Max.PV power | 4500W | 5400W | 6000W | 6900W | 7000W | 7000W | 12000W |
Max. DC voltage | 550V | ||||||
Start-up voltage | 120V | ||||||
Rated DC voltage | 360V | ||||||
MPPT voltage range | 125~500V | ||||||
No. of MPP trackers | 2 | ||||||
No. of string per MPP tracker | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 2/1 |
Max. input current | 14A/14A | 14A/14A | 14A/14A | 14A/14A | 14A/14A | 14A/14A | 30A / 15A |
Max. short current | 17.5A/17.5A | 17.5A/17.5A | 17.5A/17.5A | 17.5A/17.5A | 17.5A/17.5A | 17.5A/17.5A | 38A / 19A |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Battery type | Li-lon | ||||||
Battery voltage range | 40~58V | ||||||
Max. charge voltage | 58V | ||||||
Battery capacity | 5.12~30.72kWh | ||||||
Max. charge/discharge current | 95A / 62.2A | 95A / 75A | 95A / 83.3A | 95A / 95.8A | 95A / 104.2A | 95A / 110A | 160A / 160A |
Communication | CAN |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Rated AC power | 3000W | 3600W | 4000W | 4600W | 5000W | 6000W | 8000W |
Max. AC output current | 13A | 16A | 17.4A | 20A | 21.7A | 26A | 35A |
Rated grid voltage | L/N/PE, 220V, 230V, 240V | ||||||
Grid voltage range | 176~270V | ||||||
Rated grid frequency | 50/60Hz | ||||||
Output power factor | ~1(0.8 leading to 0.8 lagging) | ||||||
Output THDi (@Rated output) | <3% |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Rated output power | 3000W | 3600W | 4000W | 4600W | 5000W | 6000W | 8000W |
Rated output current | 13A | 16A | 17.4A | 20A | 21.7A | 26A | 35A |
Rated output voltage | 230V | ||||||
Rated output frequency | 50/60Hz | ||||||
THDv | <3% | ||||||
Overload ability | 110%, 60s /120%, 30s /150%, 10s | ||||||
Switch time | <20ms |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Max. efficiency | 97.6% | ||||||
Euro efficiency | 97.0% | ||||||
Max. battery charge/discharge efficiency | 95.0% |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
Dimension | Depending on capacity | ||||||
Weight | Depending on capacity | ||||||
Inverter topology | Non-isolated | ||||||
Noise | <35dB | ||||||
Self-consumption | <3W | ||||||
Operating temperature range | -25℃~60℃ | ||||||
Relative humidity | 0~95% | ||||||
Operating altitude | <2000m | ||||||
Cooling | Natural | ||||||
Protection degree | IP65 | ||||||
Communication | RS485,Optional: WiFi |
UHome-3K0L | UHome-3K6L | UHome-4K0L | UHome-4K6L | UHome-5K0L | UHome-6K0L | UHome-8K0L | |
EMC | EN61000 | ||||||
Safety | IEC62109-1, IEC62109-2 | ||||||
Grid | EN50549-1,VDE-AR-N-4105, CEI 0-21, UNE 206006, UNE206 007-1 |
